DIGITAL DAY / NIGHT VISION
ELECTRO-OPTICS
:
LN-G3-M50
GEN-3 DIGITAL TECHNOLOGY
DAY/ NIGHT VISION ELECTRO-OPTICS
MONOCULAR 6-36X50


Software Update

Prior to downloading the update file linked to the box above,
please check your LN-G3-M50 monocular software version.
If it matches the update version listed above, you DO NOT
need to update your monocular. Please click on the
Software Update Instructions box below and read the PDF
instructions PRIOR to downloading and running the update!

software update instructions

LN-G3-M50 Gen-3 Digital Technology Day / Night Vision Monocular Product Image 1







LN-G3-M50 Gen-3 Digital Technology Day / Night Vision Monocular Product Image 2





LN-G3-M50 Gen-3 Digital Technology Day / Night Vision Monocular Buy It Now Button Link

LN-G3-M50 Gen-3 Digital Technology Day / Night Vision Monocular Product Sheet Button Link

Instruction Manual

LN-G3-M50 Gen-3 Digital Technology Day / Night Vision Monocular Image Gallery Button Link

LN-G3-M50 Youtube video

Here is a short YouTube video product review by
Charles Lamoureux, a professional Sky Watcher
and UFO Observer, who has been buying our products
for the past 6+ years and has captured plenty of amazing
footage with them. In this video he is showing off his
latest purchase our LN-G3-M monocular
(2020 model number LN-G3-M50).




DIGITAL SENSOR - DISPLAY - WIFI - MEMORY

1920x1080 Full-HD CMOS sensor

1080p HD video recording at 60 fps

4032x3024-pixel, 12.2 MP images

HD AMOLED-Q, Quad-Pixel display

'Night Vision Green,' Color, and Black/White modes

Up to 128GB microSD memory slot

Wi-Fi transmitter for streaming data

iOS, Android via ROADCAM App

Micro-HDMI video-out port



OPTICS - ILLUMINATOR

750 mW built-in IR illuminator

All-glass optics with 50mm objective

9° angular field of view

6-36x magnification



BUILD - ERGONOMICS

3.5-hour on two CR123A batteries

14°F to 122°F working temperature

Ergonomic body & controls

Knurled rings for a sure grip

Folding rubber eyecup

1/40”-20 tripod sockets

Water resistant



Included Accessories: Daylight color enhancing filter, two CR123A batteries, a carry case, an 8 GB microSD memory card, USB adapter,  and HDMI / USB cables

One-Year Limited Warranty


  Offering all the necessary features for the 21-century outdoorsmen and Sky Watchers, the LN-G3-M50 can make a useful and fun contribution to your arsenal for hunting, bird watching, search and rescue, and stargazing adventures. To blaze through these tasks, the device sports a capable HD CMOS image sensor, color 1920x1080 HD AMOLED-Q display, Wi-Fi streaming capability, ample 128 GB storage capacity, IR illuminator, and all-glass optics. Using its enhancements, you will be able to capture high-resolution 12.2 MP still images and 1080p HD videos with rates of up to 60 fps. In addition to viewing in full color, black/white, NVD Green color modes or saving and streaming data to your mobile device, you can also connect to an HD TV display or a video recorder. To ensure clarity and detail, the 50mm objective is made from optical glass, and to provide improved long range night visibility, the monocular offers a powerful 750mW IR illuminator.

Whether you plan to visit a hot desert or to head north, this temperature- and weather-resistant monocular will perform well while also providing an ergonomic and slip-free handling experience. For mounting on tripods it also offers built-in 1/40"-20 sockets.



  TECHNICAL SPECIFICATIONS: See our Product Sheet for full specifications.


Image Sensor:  1920x1080-pixel HD CMOS sensor

Sensor Sensitivity:  0.005 lux

Still Image Resolution:  4032x3024, 12.2 MP

Video Resolution:  60 fps - 1080p, WVGA, VGA; 60/30 fps - 720p

Display:  1280x720 HD AMOLED-Q, Widescreen display

Display Size:  0.38 in (0.97 cm)

Optical System:  50mm, f/1.0, multicoated glass

Magnification:  6x-36x

Minimum Focus Distance:  2.6 ft (80 cm)

Field Of View:  9°

IR Illuminator:  850nm, 750 mW

Night Viewing Range:  438yds (400m)

Memory:  Micro-SD card, up to 128GB

Power:  Two CR123A batteries, micro-USB port

Operating Time:  3.5 hours on CR123A batteries

Operating Temperature:  14°F to 122°F (-10°C to 50°C)

Water Resistance:  Yes

Dimensions:  6.7 x 3.1 x 2.5 in (180 x 80 x 60 mm)

Weight:  18oz (510g)
